General
Device Type
Network surveillance camera
Audio Support
Yes: built-in speaker, built-in microphone
Audio Formats
G.711, G.722
Camera Mount Type
Ceiling mount
Connectivity Technology
Wired
Camera
Type
Black and white - Day&Night - fixed - indoor
Digital Video Format
MJPEG, H.264, MxPEG
Max Digital Video Resolution
3072 x 2048
Minimum Illumination
0.02 lux - B&W - shutter 1/60 sec ¦ 0.001 lux - B&W - shutter 1 sec
Video Capture
1280 x 720 @ 42 fps ¦ 1280 x 720 @ 25 fps
Features
Motion sensor, progressive scanning, temperature sensor, tamper-detection, digital PTZ function, Privacy Zone, MxBus, MxActivitySensor, Multicast Streaming, Multi Stream Transport, ONVIF (Profile S) support, built-in DVR, MxAnalytics, master/slave functionality
Image Sensor
Lens Construction
Horizontal Field of View (degree)
103
Vertical Field of View (degree)
77
Tilting
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
DHCP, FTP, HTTP, NTP, SMTP, UDP/IP, SNMP, RTSP, RTP, HTTPS, IPv4, IPv6, FTPS, SIP
Expansion / Connectivity
Ports
LAN/power - RJ-45 ¦ USB - Mini-USB Type B
Supported Memory Cards
microSD Card
Miscellaneous
Compliant Standards
EN 61000-6-2, FCC CFR47 Part 15 B, IP20, EN 55024:2010, EN 55022:2010, AS/NZS CISPR22:2009+A1:2010, IK06, EN 55032:2012, EN 61000-6-3:2007+A1:2011, EN 61000-6-1:2007, EN 50121-4:2015, EN 61000-6-4:2007+A1:2011, IEEE 802.3af
Power
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
