850nm VCSEL
Data Rate: 1.25Gbps
Single +3.3V Power Supply
RoHS Compliant and Lead-free
AC/AC Differential Electrical Interface
Compliant with Multi-Source Agreement(MSA)
Duplex LC Connector
Compliance with specifications for IEEE 802.3z Gigabit Ethernet at 1.25Gbps
Compliance with ANSI specifications for Fiber Channel applications at 1.06bps
No configuration or installation software required
Eye Safety Designed to meet LASER Class 1 comply with EN60825-1
Prestatie
SFP transceiver type
Vezel-optiek
Maximale overdrachtssnelheid van gegevens
1250 Mbit/s
Single-mode glasvezelkabel (SMF) ondersteund
Nee
Multi-mode glasvezelkabel (MMF) ondersteund
Ja
Vezel-optische connector
LC
Vezelkabel diameters ondersteund
50/125,62.5/125 µm
Tx vermogen (min)
-9,5 dBmW
Tx vermogen (max)
-3 dBmW
Netwerkstandaard
IEEE 802.3z
Certificaten
Certificaten van naleving
RoHS
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 70 °C
Temperatuur bij opslag
-40 - 85 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Inhoud van de verpakking
Aantal per verpakking
1 stuk(s)
Verpakking
Breedte verpakking
106 mm
Logistieke gegevens
Code geharmoniseerd systeem (HS)
85369010
