General
Device Type
Solid state drive array
Enclosure Type
Rack-mountable - 2U
Bundled with
4 x 32Gb SFP FC XCVR transceiver
Chassis
Installed Devices / Modules Qty
12
Supported Devices / Modules Qty
24
Storage
Total Array Capacity
23 TB
Max Supported Capacity
737.28 TB
HDD Array External Interface
32Gb Fibre Channel
Processor
Storage Controller
Type
RAID (32Gb Fibre Channel)
Data Transfer Rate
1.2 GBps
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, MSA-DP+
Storage Controller (2nd)
Hard Drive
Expansion / Connectivity
Expansion Bays
24 (total) / 12 (free) - 2.5" SFF
Interfaces
8 x 32Gb Fibre Channel
4 x mini-USB 2.0 (management)
2 x Ethernet 1000Base-T (management) - RJ-45
2 x SAS 12Gb/s (expansion port)
System Requirements
OS Required
Microsoft Windows Server, VMware vSphere, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Oracle Linux, Citrix XenServer
Miscellaneous
Features
SMTP support, SNMP support
Compliant Standards
ASHRAE Class A3, UL, CSA 62368-1, EN 62368-1, EU Lot 9, VCCI Class A, FCC Class A certified, ICES-003 Class A, EN 55032 Class A, CISPR 32 Class A, EN 61000-3-2, EN 61000-3-3, RoHS, China RoHS, WEEE
Included Accessories
2 x PDU cords (IEC C14), rack mounting kit
Manufacturer Selling Program
HPE Smart Choice
Environmental Standards
Power
Power Device
2 x internal power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-240 V 50/60 Hz
80 PLUS Certification
80 PLUS Platinum
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - parts - 3 years
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
Up to 85% RH
