General
Platform Technology
Intel vPro Platform
Bundled Services
3 Years Basic Onsite
Product Form Factor
Mini tower
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Processor / Chipset
CPU
Intel Core i7 (12th Gen) 12700
Processor Main Features
Intel Turbo Boost Max 3.0
Cache Memory
RAM
Installed Size
16 GB / 128 GB (max)
Effective Memory Speed
4400 MHz
Rated Memory Speed
4400 MHz
Slots
4 (Total) / 2 (empty)
Configuration Features
2 x 8 GB
Hard Drive
Interface Type
PCI Express
Features
NVM Express (NVMe), Class 40
Storage Controller
Optical Storage
Card Reader
Supported Flash Memory Cards
SD Memory Card, SDHC Memory Card, SDXC Memory Card
Monitor
Graphics Controller
Graphics Processor
Intel UHD Graphics 770
Video Interfaces
DisplayPort
Audio Output
Sound Output Mode
4 channel surround
Compliant Standards
High Definition Audio
Input Device
Type
Mouse (on selected markets only), keyboard (on selected markets only)
Keyboard
Keyboard Name
Dell KB216 Wired Keyboard
Mouse
Mouse Name
Dell MS116 USB Optical Mouse
Networking
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Expansion / Connectivity
Bays
1 (total) / 0 (free) x external 5.25" Slim Line ¦ Internal 3.5" ¦ Internal 2.5"
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 4.0 x4 ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 ¦ 1 (total) / 1 (free) x M.2 Card - 2230 ¦ 2 M.2 Card - 2230/2280 ¦ 1 M.2 Card - 2280
Interfaces
2 x USB 2.0 (supports SmartPower On) ¦ 1 x USB-C 3.2 Gen 2x2 (1 in front) (PowerShare) ¦ 2 x USB 3.2 Gen 2 ¦ USB 3.2 Gen 1 (2 in front) (one of them with PowerShare) ¦ 1 x headphones/microphone (1 in front) ¦ 3 x USB-C 3.2 Gen 2 (1 in front) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-out ¦ 2 x DisplayPort 1.4
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
WEEE, E-Standby, CEL, China RoHS, EU RoHS
Pricing Type
Build To Stock (BTS)
Power
Voltage Required
AC 90-264 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition + Windows 11 Pro Licence
Software
Microsoft Office (30 days trial)
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 85% (non-condensing)
