General
Device Type
Switch - 8 ports - Managed
Enclosure Type
Front to back airflow rack-mountable 1U
Ports
8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP + 2 x 10/100/1000
Power Over Ethernet (PoE)
PoE+
Performance
Switching fabric bandwidth: 24 Gbps ¦ Forwarding performance: 18 Mpps
Capacity
MAC addresses: 16000 ¦ Aggregated links (dynamic): 144 ¦ LAG groups: 64 ¦ Queues per port: 8 ¦ VLANs supported: 512 ¦ ARP entries: 2048 ¦ NDP entries: 400 ¦ Max ACL rules system-wide: 4000 ¦ ACL: 100 ¦ Maximum ACL rules per interface (IPv4) ingress rules: 1023 ¦ Maximum ACL rules per interface (IPv4) egress rules: 1023 ¦ Maximum ACL rules per interface (IPv6) ingress rules: 1021 ¦ Maximum ACL rules per interface (IPv6) egress rules: 253
MAC Address Table Size
16000 entries
Routing Protocol
IGMPv2, IGMP, IGMPv3
Remote Management Protocol
SNMP 2, SNMP, RMON, Telnet, HTTP, TFTP, SSH-2
Encryption Algorithm
AES, SSL, TLS 1.0
Authentication Method
RADIUS, TACACS+, LDAP
Features
Layer 2 switching, MDI/MDI-X switch, auto-negotiation, port mirroring, store and forward, IP address filtering, Access Control List (ACL) support, Quality of Service (QoS), fanless, LLDP support, Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), dual firmware images, MAC and IP-based ACLs support, Time-controlled ACLs support
Compliant Standards
IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, ANSI/TIA-1057, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.3ax
Expansion / Connectivity
Interfaces
8 x 10/100/1000 Base-T RJ-45 PoE+ ¦ 2 x Gigabit LAN SFP ¦ 1 x USB (service) Type A ¦ 1 x console (micro-USB)
Power
Power Device
External power adapter
Power Consumption Operational
137 Watt
Features
Front-to-rear airflow
Miscellaneous
Compliant Standards
FCC Class A certified, UL, cUL, GS, RoHS, WEEE, REACH, ICES Class A, NRTL, VCCI Class A, EAC, CCC Class A, FDA 21CFR1040.10, ACMA, FDA 21CFR1040.11, RCM Class A
Manufacturer Selling Program
CAMPUS Smart Value
Software / System Requirements
OS Required
Dell Networking OS 6
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - lifetime - response time: next business day ¦ New releases update - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
0 - 95%
Min Storage Temperature
-40 °C
Max Storage Temperature
65 °C
Humidity Range Storage
0 - 85%
