General
Device Type
Virtual network function (VNF) device
Bundled Services
15 months Next-Business-Day On-Site Response Service
Processor / Memory / Storage
Processors Installed
1 x Intel Atom C3758 2.2 GHz
RAM
8 GB DDR4 SDRAM DIMM 288-pin
Hard Drive
SSD 120 GB x 1 - M.2
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wireless, wired
Data Link Protocol
Gigabit Ethernet, Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 10 Gigabit Ethernet, IEEE 802.11n, IEEE 802.11ac
Frequency Band
2.4 GHz, 5 GHz
Features
Wall mountable, Quality of Service (QoS), Multiple SSID support, built-in Intel QuickAssist crypto acceleration, 2x2 MIMO technology
Expansion / Connectivity
Interfaces
6 x 1000Base-TX - RJ-45 ¦ 2 x 10GBase-X - SFP+ ¦ 2 x USB 3.0 ¦ 1 x console - micro-USB
Miscellaneous
Compliant Standards
CISPR 22 Class A, CISPR 24, EN55024, EN50082-1, AS/NZS 60950-1, AS/NZ 3548 Class A, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, VCCI V-3, EN 61000, CNS 13438, EN 55022 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1
Power
Power Device
External power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
20 Watt
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 85%
